DH-2328PF-A

DirectIP 28 ports switch with 24 PoE ports

  • Individual port data transmission to DirectIP NVR
  • PoE (IEEE 802.3af, IEEE 802.3at ) compliant
  • Maximum per-device PoE delivery of 380W available for 1~24 RJ45 ports
  • Central power control for greater network utility
  • Supports 24 RJ45 ports and 4 SFP slots
System
CPU 1Ghz single core
System Memory 512MB SDRAM, 256MB Flash
Switching Capacity 56Gbps
Connectivity
Copper Service Port 24 RJ45 Connectors (10/100/1000BASE-T)
Copper Uplink Port -
Optical Uplink Port 4 SFP Slot (1000BASE-X)
PoE Power
supported Standards IEEE 802.3af-2003 / IEEE 802.3at-2009
PD Connection Up to 24 IEEE 802.3af PDs or Up to 12 IEEE 802.3at PDs
PSE Power 54.5VDC, 600mA, PoE 24 ports, max. 380W
General
Diemensions(W x H x D) 440mm x 42.8mm x 268mm (17.3" x 1.7" x 10.5")
Weight 4.28kg (9.42lb)
Operating Temperature 0°C to +50°C (-32℉~ 122℉)
Power Input AC100-240V, 50-60Hz, 5.5A~2.5A
Power Consumption max 460W
Approvals FCC, CE, KC
Installation environment Accessory configuration
