5MP Fisheye Camera | NDAA & TAA Compliant
5MP
Fixed Lens
True WDR
IR Cut Filter Removable
Two-way audio
PoE
Easy Installation
ONVIF
NDAA Compliant
| Video | |
| Image Sensor | 1/1.8” CMOS |
| Max. Resolution | 2560 x 2048 |
| Scanning Mode | Progressive Scan |
| Lens Type | Fixed-focal |
| Focal Length | f=1.5mm |
| Aperture | F1.8 |
| Iris Control | Fixed Iris |
| Angular Field of View | 180°(H), 180°(V), 180°(D) |
| Pan/Tilt/Zoom | - |
| Min. Illumination | Color : 0.15 lux @ F1.8 B/W : 0.015 lux @ F1.8 |
| Dynamic Range | 120 dB (True WDR) |
| Electronic Shutter Speed | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day and Night | IR cut filter with auto switch |
| IR Distance (LEDs) | - |
| Image Setting | Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control), 3DNR Level, WDR Level |
| Backlight Compensation | On / Off |
| Image Stabilizer | - |
| Privacy Masking | 8 Zones |
| Intelligent Video | Video Motion Detection, Active Tampering Alarm, Trip Zone, Heatmap |
| Viewing Composition | 1O |
| Video Out | - |
| Network | |
| Video Compression | H.265, H.264 (MP), M-JPEG |
| Intelligent Codec | Supported |
| Bitrate Control | H.264 - CBR / VBR, H.265 - CBR / VBR |
| Audio Compression | ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law |
| Two-way Audio | Yes |
| IP Camera Protocol | DirectIP 2.0, ONVIF Profile S |
| Max. Frame Rate | 30ips : 2560 x 2048 (WDR) |
| Supports Resolution | 2560x2048, 640x512 |
| Multi-video Streaming | Quadruple Streaming |
| Network Protocols | DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Security | SSL Encryption, Multi-user Authority, IEEE 802.1x ,IP Filtering, HTTPS |
| Remote Access Client | DirectIP NVR Connection, IDIS Web, IDIS Mobile, IDIS Solution Suite |
| Ethernet | RJ45 (10/100BASE-T) |
| Recording Session Buffer (NLTSrec) | Yes (Up to 60MB) |
| Edge Storage | micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| ALARM AND EVENT | |
| Trigger Event | Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone, Heatmap |
| Event Notification | - |
| Audio In/ Out | 1(Built In MIC) 1 / 1 |
| Alarm In / Out | 1/1 |
| Environmental | |
| Vandal Proof Casing | - |
| Outdoor Ready | - |
| Operating Temperature | -10°C ~ 50°C (-22°F ~ 122°F), Starting up at above 0°C (32°F) |
| Operating Humidity | 0% ~ 90% |
| Electrical | |
| Power Source | PoE (IEEE 802.3af Class 2) |
| Power Consumption | PoE (IEEE 802.3af Class 2), 5.6W |
| Approval | FCC, CE, KC |
| Mechanical | |
| Dimensions (Ø x H) | Ø122 x 35.8mm(Ø4.80 |
| Weight | 0.280kg (0.62 lb) |
| Installation environment | Accessory configuration |
|
Wall |
Tilt Mount
Model: DA-TM4100
or
MOUNT ADAPTER
Model: DA-MA4300
+
WALL MOUNT
Model: DA-WM2050
or
JUNCTION BOX
Model: DA-JB4700
|
|
Celling |
Tilt Mount
Model: DA-TM4100
or
MOUNT ADAPTER
Model: DA-MA4300
+
CEILING MOUNT
Model: DA-CM2050
or
JUNCTION BOX
Model: DA-JB4700
|
|
Pole |
MOUNT ADAPTER
Model: DA-MA4300
+
WALL MOUNT
Model: DA-WM2050
+
Pole Mount
Model: DA-LM2000
or
JUNCTION BOX
Model: DA-JB4700
+
Pole Mount
Model: DA-LM2000
or
Tilt Mount
Model: DA-TM4100
+
Pole Mount
Model: DA-LM2000
|
|
Corner |
MOUNT ADAPTER
Model: DA-MA4300
+
WALL MOUNT
Model: DA-WM2050
+
Corner Mount
Model: DA-RM2000
or
JUNCTION BOX
Model: DA-JB4700
+
Corner Mount
Model: DA-RM2000
or
Tilt Mount
Model: DA-TM4100
+
Corner Mount
Model: DA-RM2000
|
