| Video |
| Image Sensor |
1/2.8" CMOS |
| Max. Resolution |
1920 x 1080 |
| Scanning Mode |
Progressive Scan |
| Lens Type |
Fixed-focal |
| Focal Length |
f=2.8mm |
| Aperture |
F2.0 (f=2.8mm) |
| Iris Control |
Fixed Iris |
| Angular Field of View |
111.6°(H), 61.45°(V), 127.3°(D) |
| Pan/Tilt/Rotate Range |
Pan: -170° ~ 170°, Tilt: -5° ~ 67.5°, Rotate: -109° ~ 109° |
| Min. Illumination |
COLOR : 0.2 lux @ F2..0
B/W : 0 lux (IR LED ON) |
| S/N Ratio |
More than 45dB |
| Dynamic Range |
120dB |
| Electronic Shutter Speed |
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day and Night |
IR cut filter with auto switch |
| WDR |
WDR |
| IR Distance (LEDs) |
30m / 98.4 ft (4ea) |
| Image Setting |
Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control) |
| Backlight Compensation |
On / Off |
| Mirroring / Pivot |
Horizontal / Vertical / Pivot |
| Image Stabilizer |
- |
| Privacy Masking |
8 Zones |
| Intelligent Video |
Video Motion Detection, Active Tampering Alarm, Trip Zone |
| Video Out |
- |
| Network |
| Video Compression |
H.265, H.264 (MP) M-JPEG, |
| Intelligent Codec |
Supported |
| Video Compression Level (Quality) |
Basic, Standard, High, Very High |
| Bitrate Control |
H.265 - CBR / VBR, H.264 - CBR / VBR |
| Audio Compression |
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law
|
| Two-way Audio |
Yes |
| IP Camera Protocol |
DirectIP 2.0, ONVIF Profile S |
| Max. Frame Rate |
30ips : 1920 x 1080(WDR) |
| Supports Resolution |
1920x1080, 1280x720, 640x360, 352x240 |
| Multi-video Streaming |
Quadruple Streaming |
| Network Protocols |
DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Security |
SSL Encryption, Multi-user Authority, IEEE 802.1x, IP Filtering, HTTPS |
| Remote Access Client |
DirectIP NVR Connection, IDIS Web, IDIS Mobile, IDIS Solution Suite |
| Ethernet |
RJ45 (10/100BASE-T) |
| Recording Session Buffer (NLTSrec) |
Yes (Up to 60MB) |
| Edge Storage |
micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| ALARM AND EVENT |
| Trigger Event |
Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone
|
| Event Notification |
Remote S/W, Email (with Image) |
| Audio In/ Out |
1(Built MIC)+1 / 1 |
| Alarm In / Out |
1 / 1 |
| Environmental |
| Vandal Proof Casing |
- |
| Outdoor Ready |
- |
| Material |
Plastic |
| Operating Temperature |
-10°C ~ +50°C (+14°F ~ +122°F), Starting up at above 0°C (32°F) |
| Operating Humidity |
0% ~ 90% |
| Electrical |
| Power Source |
PoE (IEEE 802.3af Class 2) |
| Power Consumption |
PoE, IEEE 802.3af (Class 2), 4.6W |
| Approval |
FCC, CE, KC |
| Mechanical |
| Dimensions (Ø x H) |
Ø110 x 88mm(Ø4.33” x 3.46”) |
| Weight |
0.26kg(0.57lb) |
2MP
Fixed Lens
True WDR
Easy Installation
Two-way audio
PoE
IR Cut Filter Removable
ONVIF
